Fast Speed Plastic 2mm Blister Forming Machine Three Station Pp Pvc Pet

    Buy cheap Fast Speed Plastic 2mm Blister Forming Machine Three Station Pp Pvc Pet from wholesalers

    Buy cheap Fast Speed Plastic 2mm Blister Forming Machine Three Station Pp Pvc Pet from wholesalers
    • Buy cheap Fast Speed Plastic 2mm Blister Forming Machine Three Station Pp Pvc Pet from wholesalers

    Fast Speed Plastic 2mm Blister Forming Machine Three Station Pp Pvc Pet

    Ask Lasest Price
    Brand Name : BoHai
    Model Number : BH-7177
    Certification : CE
    Price : Negotiate
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : Two in a month
    Delivery Time : 20day
    • Product Details
    • Company Profile

    Fast Speed Plastic 2mm Blister Forming Machine Three Station Pp Pvc Pet

    High Speed Plastic Blister Forming Machine Three Station Pp Pvc Pet


    The whole machine adopts full servo control, the positioning is more accurate, and the molding is more stable. The equipment has the advantages of stable operation, low noise, energy saving and environmental protection, and high grade of finished products.


    Product Paramenters
    Max. Forming Area
    750*480mm
    650*320mm
    Max. Forming Depth
    125mm(custom height)
    Sheet Thickness
    0.3-1.8mm
    Sheet Width
    760mm
    650mm
    Max. Forming Speed
    35 times/min
    Air Pressure
    0.6-0.8mpa
    Air Consumption
    3.0m³/min
    2.0m³/min
    Water Consumption
    0.7m³/h
    0.5m³/h
    Rated Power
    140Kw
    98Kw
    Used Power
    98Kw
    69Kw
    Power Supply
    AC 380V,50Hz, Three-phase, Four-wire
    Dimension
    L8500*W2200*H3100mm
    L6000*W2000*H2700mm
    Weight
    About 6.5T
    About 5T

    The temperature control system of the electric heating furnace adopts full computer intelligent automatic compensation control. Long life and other advantages. With product data and parameter file memory function. The width of the film feeding chain can be adjusted automatically or separately.
