Polystyrene Lid Blister Forming Machine Positive Air Pressure Four Stations

    Buy cheap Polystyrene Lid Blister Forming Machine Positive Air Pressure Four Stations from wholesalers

    Buy cheap Polystyrene Lid Blister Forming Machine Positive Air Pressure Four Stations from wholesalers
    • Buy cheap Polystyrene Lid Blister Forming Machine Positive Air Pressure Four Stations from wholesalers

    Polystyrene Lid Blister Forming Machine Positive Air Pressure Four Stations

    Ask Lasest Price
    Brand Name : BoHai
    Model Number : BH-7177
    Certification : CE
    Price : Negotiate
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : Two in a month
    Delivery Time : 20day
    • Product Details
    • Company Profile

    Polystyrene Lid Blister Forming Machine Positive Air Pressure Four Stations

    Lid Machine Blister Forming Machine Positive Air Pressure


    1. positive and negative pressure forming device.
    2. vacuum forming device.
    3. touch screen computer temperature module point to point control function.
    4. air control device.
    5. cooling device.

    6.die, mold temperature control function.
    7.automatic punching and cutting function.
    8.automatic stack counting function.
    9.edge automatic rewinding function.
    10.safety protection device.


    Product Paramenters

    Station
    Four stations
    Three station
    Four stations
    Three station
    Model
    TTF-700AF
    TTF-700A
    TTF-520AF
    TTF-520A
    Forming Area
    700mm x 550 mm
    520mm x 400 mm
    Forming Depth (Max.)
    120mm
    110mm
    Sheet thickness
    0.2-2.0mm
    Forming Speed (Max.)
    35times/min
    30times/min
    Air pressure
    0.6-0.8mpa
    Air consumption
    3.6 m³/min
    3.0 m³/min
    Water consumption
    0.8 m³/h
    0.7 m³/h
    Sheet width (Max.)
    730mm
    550mm
    Suitable Sheet
    PP, PS, HIPS, PET, PVC, PLA etc.
    Power supply
    AC 380V, 50Hz, Three-phase, Four-wire
    Used power
    105Kw
    95Kw
    55Kw
    50Kw
    Rated power
    210Kw
    190kw
    110Kw
    100Kw
    Heating power
    118Kw
    75Kw
    Procedure
    Forming-punching-
    cutting-stacking
    Forming-cutting-
    stacking
    Forming-punching-
    cutting-stacking
    Forming-cutting-
    stacking
    Dimension
    L14000*W4700*
    H2750mm
    L13000*W4700*
    H2750mm
    L11000*W4600*
    H2700mm
    L9700*W4600*
    H2700mm
    Weight
    About 25.0T
    About 19.0T
    About 11.0T
    About 9.0T
